New Product Launch: FITOK Ultra High Purity High-Capacity Check Valves
08/06/2024
364
Introduction
FITOK CB Series Ultra High Purity High-Capacity Check Valves are engineered for low pressure and high flow bulk gas distribution applications. These valves are suitable for use with inert gases as well as most toxic gases, effectively preventing undesired reverse flow within the high purity system.
Features
- Metal-to-metal seal between valve body and bonnet
- Packless design eliminates particle contamination from packing wear
- Integrated purge port on valve body for easy purging
- Low cracking pressure and high sensitivity
- High flow capacity with a flow coefficient (Cv) of up to 165.5
- Connection tube in customized length available
Technical Data
Port Size | 3/4" to 4" | ||
Flow Coefficient (Cv) | 10.96 ~ 165.5 | ||
Working Pressure | Vacuum to 250 psig (17.2 bar) | ||
Working Temperature | -15 ~ 250 °F (-5 ~ 121 °C) | ||
Cracking Pressure | ≤ 1.8 psig (0.12 bar) | ||
Full Open Pressure | 4 ~ 12 psig (0.28 ~ 0.83 bar) | ||
Reseal Pressure (Back Pressure) | ≤ 5 psig (0.34 bar) | ||
Leak Rate (Helium) | Internal | ≤ 1×10-9 std cm3/s | |
External | Inboard | ≤ 1×10-9 std cm3/s | |
Outboard | ≤ 1×10-9 std cm3/s |
In addition to CB Series Ultra High Purity High-Capacity Check Valves, FITOK offers All-Welded Check Valves (CW series) and general check valves (CV, CH, CO, CA, COA and CL Series) for various applications.
Please see the CB Series Ultra High Purity High-Capacity Check Valves Catalog for more information. Should you have any questions, please contact us directly and we will reach you soon.
